Product Details:
Payment & Shipping Terms:
|
| Product Name: | Stair Screen | Application: | Water Treatment |
|---|---|---|---|
| Material: | CS Or SS | Standard: | ISO |
| Motor Power: | 0.75～3.0KW | Structure: | Compact Connection |
| High Light: | water purification screening,rotary bar screen |
||
Specifications:
|
Screen width B(mm) |
600～3000 |
|
Channel width B1(mm) |
B+100 |
|
Channel depth H(m) |
1.5～10 |
|
Angle (°) |
60～75 |
|
Mesh diameter (mm) |
3,5,6, 8, 10 |
|
Operating speed (m/min) |
~3.8 |
|
Motor power(kW) |
0.75～3.0 |
|
Wash water pressure(MPa) |
≥0.3 |
|
Maximum water head(m) |
1.0 |
Overview
WJG Ladder type bar screen is widely used in urban sewage and industrial waste water and the removal of the suspended the floating-debris, also can used for the pumping station of dirt, water treatment is cleared the ideal equipment.
structure and working principle
Staged bar screen mainly by the dynamic bar screen, static bar screen, power and transmission equipment, electrical control four components. Action for serrated grating type staggered, through the transmission mechanism driving dynamic bar screen do turn sewage, eccentric movement from static grid's a step to the next level, until the top pick up and fall into the bar screen slot.
the main character
The bar screen no underwater moving parts, so work no dirt card plug phenomenon, smooth and reliable operation;
Bar screen piece, without changing flow cascade use convenient in maintenance,
The installation of the bar screen can be used platform closed structure, appearance generous, do not affect the surrounding environment health;
Operation can adopt manual and automatic control, safety operation and reliable;
Underwater sections can adopt stainless steel, the corrosion resistance and long service life.
