Product Details:
Payment & Shipping Terms:
|
| Usage: | Construction Hoist | Dimension(L*W*H): | Customized |
|---|---|---|---|
| Loder Weight: | 2t / 4t | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Elevator Classification: | Normal / Frequency | Cage: | Single / Double |
| Port Of Delivery: | Shanghai / Ningbo | Warranty: | 12 Months |
| High Light: | construction hoist,construction material lift |
||
SC200/200 VFFF Speed single / double cage hoist for construction supplier
Quick Details
Standard Model Specification
This style construction equipment
1, Adopts computer aided design
2, Light, easty to operate
3, Lifting capacity can reach up to 1 to 2 tons
4, Running speed can reach 28 to 38m/min
5, use VVVF speed regulation enable 0 to 68m/min range
6, PLC, provide automatic layer selecting and leveling as required
7, Anti-corrosion treatment for the internal and external mast
|
Name |
Unit |
SC100 |
SC100/100 |
SC200 |
SC200/200 |
|
(kg) Rating loading capacity |
Kg |
1000 |
2×1000 |
2000 |
2×2000 |
|
Passenger number |
Person |
12 |
2×12 |
16 |
2×16 |
|
Rating rising rate |
M/min |
36 |
36 |
36 |
36 |
|
(m) Max. promoting height |
m |
200 |
200 |
200 |
200 |
|
Motor power |
KW |
2×11 |
2×2×11 |
3×11 |
2×3×11 |
|
Cage size |
m |
3*1.5*2.5 |
3*1.5*2.5 |
3*1.5*2.5 |
3*1.5*2.5 |
|
650 mast section weight |
Kg |
124 |
148 |
124 |
148 |
|
650 mast section length |
mm |
650×650 ×1508 |
650×650 ×1508 |
650×650 ×1508 |
650×650 ×1508 |
|
Steeve rating rising weight |
Kg |
200 |
200 |
200 |
200 |
Our Advantage
Our products are mainly, but not limited to the following:
1. Building Hoist/Elevator/Lift (For both personnel and materials)
SC Building Hoist is a vertical handling machine dedicated for both personnel, tools, and materials widely applied in building construction, industrial and mining, multi-storey workshop, warehouse, station, wharf, etc.
SC series Building Hoist has a variety of configurations: Frequency conversion system, Monitoring equipment, Layer stop protection device, GPS layer selecting system, Microcomputer wind speed device and so on, which are optional as required.
Our Building Hoist adopted computer aided design. Comparing with traditional building hoists, it is attractive, light, easy to handle, secure, applicable, and popular.
2. Material Hoist/Elevator/Lift (For materials only)
Material Hoist is a vertical handling machine dedicated for materials widely applied in building construction, industrial and mining, multi-storey workshop, warehouse, station, wharf, etc. It is convenient, efficient, and secure.
3. Aerial Work Platform/Cradle/BMU/Gondola
Suspended platform is ideal equipment for nearly all kinds of construction work or complex environmental projects, where it needs to lift people, their working tools and materials to a certain level of height. It’s a fast, secure, strong, reliable, efficient, and economic means of access widely used all over the world.
It is widely used in the following areas: high-rise elevator cable installation, granary, coal well, anti-theft security, the construction, decoration and maintenance of high-rise building, glass curtain walls and chimney, shipping industry, dam, bridge and so on.
4. Jack Gantry Lift
SMZ150-1 Self-propelled Jack Gantry Lift is a new type of vertical transportation machinery widely applied to building construction, exterior/interior decoration, housing maintenance, and other fields. It is popular, convenient, secure, and economic.
5. Concrete Mixer, Concrete Pump, Concrete Spreader
6. Components
Hoist, safety lock, steel rope, distribution box, counter weight, suspender, etc.
Product Show
Please supply more detail to us:
1. Lift capacity
2. Lift height
3. Local voltage
