Passenger and Goods Construction Material Hoist Double Cage SC200 / 200

Customized Color Alimak Technology Construction Material Hoist With Figured Aluminum Plate




Quick Detail:


Product Application

We are special supplier of building hoist in China, our building hoist have been widely exported to all over the world and won good reputation, whose payload capacity is as much as 5000kg, lifting speed can reach up to 96m/min, and the erection height reaches up to 550m, our products have been widely used for transportation for both men and cargo in field of general buildings, but also industry, electric power, mining well, oil, chemical industry etc.

Construction Material Hoist:

1. Each cage load capacity: 2000kg

2. Lifting speed: 36m/min or 63m/min or 96m/min

3. Mast section: Paint or hot dipping zinc

4. Cage: Single cage or twin cage

5. Recommended cage inner dimension (LxWxH)(m): 3.0x1.3 x2.2, 3.0x1.3x2.2, 3.2x1.5x2.2, 3.6x1.5x2.2, 3.8x1.5x2.2, 4.0x1.5x2.2, 4.2x1.5x2.2, 5x1.5x2.2, cage dimension is according to requirement of customer and special project.

6. Motor and reducing device: Made in China, can be SEW Germany, Schneider and other world class brand according to requirements.

7. The colors of cage: Yellow, or red, or blue or any color as your requests.

8. Other each cage load capacity for your to choose: 1000kg, 1500kg, 2000kg, 2700kg, or 3200kg.

Product Feature:

1. Better safety control system.

2. High operational reliability.

3. Easy to use (install, dismount and maintain).

4. CE and ISO compliant.

5. Exceptional service and technical support.

6. Nice price, Will be within your budget.

Specifications

Characteristics:

The construction lifting equipment is the new-generation product designed with advanced technology from domestic and abroad introduced to our company.

Compared with traditional construction hoist, the new generation SC series is more comfortable, safe, reliable and convenient for dismantling and maintenance with more reasonable and compact structure, strong and durable cages, attractive appearance and precise parts.

There are many type of driven mechanisms include three-motors, two motors and energy saving new type etc. The transmission plate is fitted at the top of cage to avoid any header accident and provide a comfortable cage for passengers and materials.

Floor calling system, over load limiter, volt displayer are integrated on control panel for convenient operation. Many patent technologies such as anti-derail technology are used on each guide wheels to ensure safe running.

Competitive Advantage:

1). Compact design and comfortable operation environment

2). Proven helical gearbox as an option

3). Single and double cage configurations

4). Design without countweight

5). Multiple choices of doors

6). Simple and easy operation system

7). Recessed control panel

8). PLC control as an option

9). Dorable materials:high quality steel for increased strength and weight reduction,hot dip

10). galvanized mast section and tie-in

11). Wide range of tie-in

12). Wide range of optional equipment and functions

Technical Specifications

Safety Features

--Parachute brakes

 --Double motor-group with both brakes and centrifuge brakes

 --Emergency stop

 --End of course switch to limit the final mast. Final mast detector.

 --Manual descent in case of emergency or power supply off

 --Final mast without rack --Maneuver acoustic alarm

 --Upper and lower floor detector with an approaching slow speed selector.
