Double Cage Building Site Hoist

Double Cage Building Site Hoist
Double Cage Building Site Hoist Double Cage Building Site Hoist Double Cage Building Site Hoist Double Cage Building Site Hoist

Large Image :  Double Cage Building Site Hoist Get Best Price

Product Details:

Place of Origin: China
Brand Name: Boruida
Certification: CE
Model Number: -

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Pack in container
Delivery Time: 30-45 working days
Payment Terms: T/T before shipment, LC at sight
Supply Ability: 40pcs a month
Detailed Product Description
High Light:

hoisting equipment in construction

,

building material hoist



Red Painted Double Cage Building Site Hoist With 0 - 60m/min Wide Range Of Tie-in





Quick Detail:



Name

other name

Brand Name

Control

Building Hoist

Building Hoist SC 160/160

BORUIDA

DOL and FC

Loading Capacity

1600kg/1600kg

Certificate

CE





Description:



Building Hoist SC 160/160 is installed and dismounted conveniently and can grow as high as the building grows height.The Building Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.It is efficient and safety vertical transporting equipment



Applications:



SC serialization of products Building Hoist is a Rack and Pinion EL. Building Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.



Specifications



Standard technical datas of  double cage :



Parameter

SC100/100

SC160/160

SC200/200

SC270/270

SC320/320

Rated
loading capacity
(kg)

1000/1000

1600/1600

2000/2000

2700/2700

3200/3200

Rated lifting speed
(m/min)

0~40

0~40

0~60

0~60

0~60

Rated passenger number

12/12

18/18

24/24

30/30

38/38

Max. lifting height(m)

150

250

450

450

450

Engine power(kW)

2*2*9.5

2*2*11

2*2*13

2*3*18.5

2*3*22

Cage inner dimension
(L*W*H)(m)

3*1.3*2.5

3*1.4*2.5

3*1.5*2.5

3.2*1.5*2.5

3.6*1.6*2.5

Cage weight (kg)

1400

1500

1800

1950

2050

Mast section weight
(kg)

145

145

163

163

163

Mast section dimension

(mm)

650*650*1508

650*650*1508

650*650*1508

650*650*1508

650*650*1508

Safety device type

 SAJ30-1.2

SAJ40-1.2

SAJ40-1.4

SAJ40-1.4

SAJ50-2.0

Hanger rated lifting

capacity
(kg)

250

250

250

250

250

Rack module

8

8

8

8

8





SC series building hoists:



1). Cage load capacity: 1000kg~3200kg;

2). Lifting speed:30m/min, 0~40m/min;0~60m/min;

3). Increased lifting height on request;

4). Mast section: Painted or hot dipped zinc

5). Cage:double cage

6). Recommended cage inner dimensions (L*W*H): 3*1.3*2.5m, 3*1.4*2.5m, 3*1.5*2.5m, 3.2*1.5*2.5m, 3.6*1.5*2.5m, according to requirements of customers;

7). Motor and reducing device: Made in China, or uses SEW according to requirements

8). Color of cage: Yellow, red, blue or your request

9). Cage load capacity: 1, 000kg, 1, 600kg, 2, 000kg, 2, 700kg or 3, 200kg

10). including VFD or without VFD.



Competitive Advantage:



1). Compact design and comfortable operation environment

2). Proven helical gearbox as an option

3). Single and double cage configurations

4). Design without countweight

5). Multiple choices of doors

6). Simple and easy operation system

7). Recessed control panel

8). PLC control as an option

9). Dorable materials:high quality steel for increased strength and weight reduction,hot dip

10). galvanized mast section and tie-in

11). Wide range of tie-in

12). Wide range of optional equipment and functions
