| Product Name: | Industrial Hoist | Lifting Height: | 20m |
|---|---|---|---|
| Lifting Speed: | 36m/min | Control System: | DOL |
| Brand: | BORUIDA | Surface Treatment: | Hot Galvanized |
| High Light: | construction material lift,material hoisting equipment |
||
60m / min Construction Material Hoist 2700kg for Warehouse / High Tower
Contracting
Boruida's 10 years experience helped us to learn how important is the attention on details, quality and a work finished on time. We can demonstrate it through our big number of satisfied customers along this years. Our main goal is to give our customers high quality products, guarantee and a customized monitoring of every detail by using new construction technologies for new buildings. On the other hand, for renovations, we use very exclusive solutions.
Quick Detail:
Name | Other Name | Brand Name | Control |
Construction Hoist | Construction Hoist SC 270 | BORUIDA | DOL and FC |
Loading Capacity | 2700kg | Certificate | CE |
Description:
Construction Hoist SC 270 is installed and dismounted conveniently and can grow as high as the building grows height.The Construction Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
SC serialization of products Construction Hoist is a Rack and Pinion EL. Construction Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications:
Standard technical datas of single cage :
Parameter | SC100 | SC160 | SC200 | SC270 | SC320 |
Rated | 1000 | 1600 | 2000 | 2700 | 3200 |
Rated lifting speed | 0~40 | 0~40 | 0~60 | 0~60 | 0~60 |
Rated passenger number | 12 | 18 | 24 | 30 | 38 |
Max. lifting height(m) | 150 | 250 | 450 | 450 | 450 |
Engine power(kW) | 2*9.5 | 2*11 | 2*13 | 3*18.5 | 3*22 |
Cage inner dimension | 3*1.3*2.5 | 3*1.4*2.5 | 3*1.5*2.5 | 3.2*1.5*2.5 | 3.6*1.6*2.5 |
Cage weight (kg) | 1400 | 1500 | 1800 | 1950 | 2050 |
Mast section weight | 145 | 145 | 163 | 163 | 163 |
Mast section dimension (mm) | 650*650*1508 | 650*650*1508 | 650*650*1508 | 650*650*1508 | 650*650*1508 |
Safety device type | SAJ30-1.2 | SAJ40-1.2 | SAJ40-1.4 | SAJ40-1.4 | SAJ50-2.0 |
Hanger rated lifting capacity | 250 | 250 | 250 | 250 | 250 |
Rack module | 8 | 8 | 8 | 8 | 8 |
SC series construction hoists:
1). Cage load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Cage:double cage
6). Recommended cage inner dimensions (L*W*H): 3*1.3*2.5m, 3*1.4*2.5m, 3*1.5*2.5m, 3.2*1.5*2.5m, 3.6*1.5*2.5m, according to requirements of customers;
7). Motor and reducing device: Made in China, or uses SEW according to requirements
8). Color of cage: Yellow, red, blue or your request
9). Cage load capacity: 1, 000kg, 1, 600kg, 2, 000kg, 2, 700kg or 3, 200kg
10). including VFD or without VFD.
The lift for people and material has the best characteristics for work:
- Optimized modular design to make it tough but light.
- Improved with the more useful technology to have a fast installation process and an easy and continuous operation. With a modern system of operation management, where it’s necessary to mention their excellent preventive maintenance. It facilitates to the user the communication with the elevator.
- Use the same kind of mast and their component respect to the rest of our products.
- It has a flexible cabin that allows our new elevator to have different available spaces or to become either a Lift or a Transport Platform.
- Can carry up to 20 people or 2000 Kg
