Powered Suspended Platform Cradle Gondola for external wall , cleaning window

Powered Suspended Platform Cradle Gondola for external wall , cleaning window
Powered Suspended Platform Cradle Gondola for external wall , cleaning window Powered Suspended Platform Cradle Gondola for external wall , cleaning window Powered Suspended Platform Cradle Gondola for external wall , cleaning window Powered Suspended Platform Cradle Gondola for external wall , cleaning window

Large Image :  Powered Suspended Platform Cradle Gondola for external wall , cleaning window Get Best Price

Product Details:
Place of Origin: China (Mainland)
Brand Name: NEWORLD
Certification: ISO CE SGS
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set / Sets
Price: Negotiation
Packaging Details: Standard type, pls consult our manager for detail solution
Delivery Time: within 15 working day after receiving the payment
Payment Terms: L/C, T/T, Western Union, Pay Pal
Supply Ability: 800 Set / Sets per month
Detailed Product Description
Key Word: Suspended Platform Cradle Quality: Superior
Port Of Delivery: Shanghai Warranty: 12 Months
Feature: Durable Trouble-free Operation Corrosion Resistance Reliable In Safety
High Light:

Suspended Cradles

,

construction platform

Powered Suspended Platform Cradle Gondola for external wall,cleaning window

Quick Details


Place of Origin:
Jiangsu China (Mainland)
Brand Name:NEWORLDModel Number:
ZLP800
Name:
suspended platform
Rated Load:
800kg
Rated Lifting Speed:
8.2±0.5m/min
Length of platform:
7500mm
Surface Proceeding:
steel and aluminum
Hoist power:
2 x 1.8kw
Voltage:
380V, 50HZ, Three-Phase
Counter weight:
1000kg
Locking cable:
3-8


Specifications

ZLP series suspended platform can be devided into two kinds of specifications,ZLP630 and ZLP800.

Working Principle of suspended platform:
It is driven by electric hoist and wire rope, running against the building facade while the suspension mechanism was erected on buildings or structures.


 Model ZLP630ZLP800
Suspended Platform
1m,2m,3m,1.5m,2.5m
to the length made.
In any Combination
Rated Load630KG800KG
Rated Lifting Speed9.3±0.5m/min8.2±0.5m/min
Length of Platform6000mm7500mm
Surface Proceeding Aluminum;steel materials(Galvanized,Spraying)
Lifting Height100m100m
Cable100m100m
Max Lifting Height200m200m
Steel Rope8.3mm9.1mm
HoistPower1.5KW*21.8KW*2
Voltage380V, 50HZ, Three-Phase(standard)
Safety LockPermission Force of Impact30KN30KN
Locking Cable Angle3°~ 8°3°~ 8°
Suspension MechanismFront Beam Overhang1.3 ~ 1.5m ±0.261.3 ~ 1.5m ±0.26
Support Adjustable Height  1.44 ~ 2.14m ±0.26  1.44 ~ 2.14m ±0.26
Counter Weight1000KG1000KG
20' GP Container9sets8sets
40' GP Container12sets12sets
40'HQ Container27sets(without couter weight)


Frame platform assembled by Steel (Aluminum) panels and bolts, used for carry workers and construction tools.platform have Aluminum,Steel with Plastic coating fihish, Steel with Hot dip galvanized finish three kinds for choose.

1 Features for Aluminum platform:
No need painting or galvanizing on surface;
Oxygen membrane on the surface, rust-proof, anti-corrosion.
Light weight, 65% lighter than the same model of steel one.
Load effiency increased, anti-subversion ability improved.
Easy to install& operate.
Good look, with bright silver gray color
2 Features for Steel platform with Plastic coating finish:
Plastic painting on platform surface, anticorrosion.
With comptitive price compared with the aluminum and hot-galvanized surface.
3 Hot dip galvanized steel platform.
With good ourlook;
Anti corrosion.
Lower price than Aluminum platform.
Advantages:
Platform length varies from 1 m, 1.5 m, 2 m, 2.5 m, to 3 m range. Customers can assemble them free as required.
End frame: the first factory adopts raglan welding treatment. Secure, greatly enhancing the strength and safety of the platform.
Embossing bottom plate width is 720mm, flat shape, easy for installation.
360 caster wheels are under bottom, facilitate moving the platform.



Our Services:
1- One year warranty for whole machines.
2- Providing free quick-wear part.
3- Low charge for continue maintenance when warranty is expired.
4- Exclusive engineer support at any time.
5- free training to end-users.
6- 24 hours online service and support


Advantages:
1,NEWORLD uses the the rolled steel from national large iron and steel company wholly.
2,  all of the rolled steel,welding material and key materials are tested before transporting to the workshop
3, our company has a strong and professional team in charge of new product research and update.
4, our products are made according to the drawing strictly, using 16Mn, 40Cr and 45# steel.
5, the front point of the crane arm is equipped with anti-warping device additionally.
6, the structure of tower adopts intensive form , excellent rigidity, without deformation.
7, the slewing tower body and standard section are processed by the double milling surface.
Good level of junction surface. Excellent stability, little wear of the slewing bearing. Long using life.
8, the safety equipment adopts the products from the first-rate manufacturer.
9, we adopt the submerged arc welding and carbon dioxide arc welding wholly. We use Imported welding
manipulator in the important parts, with advanced technology and high strength of connection
