VFC Control Construction Hoist Elevator with Rack , Construction Material Handling Equipment

VFC Control Construction Hoist Elevator with Rack, Construction Material Handling Equipment


Ground Enclosure for Construction hoist elevator

Consists of a base to support the mast and railing. A single cage enclosure can be transformed into a twin cage enclosure by adding just a few parts.



Quick Detail:



Description:

1. Construction lifting hoist SC 270 is installed and dismounted conveniently and can grow as high as the building grows height.
2. The Construction lifting hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
3. It is efficient and safety vertical transporting equipment



Applications:

SC serialization of products Construction lifting hoist is a Rack and Pinion EL. Construction lifting hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.


Specifications

Standard technical datas of single cage :

Construction hoists elevator specifications:

1. Cage load capacity: 1000kg~3200kg, can be customized as requirements.

2. Lifting speed: 33m/min, 0~40m/min, 0~60m/min, 0~96m/min.

3. Increased lifting height on request.

4. Mast section: Painted or hot dipped zinc.

5. Mast section: 650 or 450.

6. Cage: double cage or single cage.

7. Door types: Vertical sliding door, Vertical door with manual bridge, Vertical sliding door C side. (Optional).

8. Recommended cage inner dimensions (L*W*H): 3*1.3*2.2m, 3*1.4*2.2m, 3*1.5*2.2m, 3.2*1.5*2.2m, 3.6*1.5*2.2m, up to requirements of customers.

9. Motor and reducing device: Made in China, or using SEW, Schneider, Nord and other world class brand drive units, up to requirements.

10. Color of cage: Yellow, red, blue, white, green or any color as your request.

11. Cage load capacity: 1, 000kg, 1, 500kg, 2, 000kg, 2, 700kg or 3, 200kg or increased as demand.

12. With VFD or without VFD.

13. Double mast available.

14. Electrical and mechanical double safety lock system.

RFQ

Q: What is the building hoist main purpose?
A: Building hoist equipped with double or single cabin to transport the materials and labors up and down. It's the ideal construction equipment for vertical transportation in the field of construction.

Q: What is the main structure of building hoist?
A: The P/M construction hoist mainly contains metal structure, driving system, electrical control system, cable guide & protection system, electrical top crane and safety device.

Q: What is the meaning of the building hoist’s code?
A: Take SC200/200 for example: “SC” stands for rack and pinion hoist, “200/200” stands for double cage and capacity is 2 tons per cage. “SC200” stands for single cage and capacity is 2 tons.

Q: What is the dimension of the cage?
A: Normally the cage dimension is 3X1.5X2.2M (L/W/H) for 2t type hoist. Details should be checked according to our quotation sheet. Also, the size can be customized according to the factual site condition. There are two doors (entrance & exit doors) for each cage, It can be produced as up & down sliding or ramping model for safety and convenience.
